Saltillo tile floor in a warm terra cotta color layed in a Versailles pattern. Dark wood desk in the foreground with dark leather chair.

THREE-TILE PATTERNS

Create designs with a high degree of movement and flow using three-tile patterns. Compare pattern styles, tile size and more to find your perfect design.
Tile pattern created with one square tile, two rectangular tiles equaling the dimensions of the square tile, and four smaller square tiles equalling the dimensions of the square tile.

Divisible

33 pcs. per 100 s/f
12" x 12" 34%
67 pcs. per 100 s/f
6" x 12" 33%
134 pcs. per 100 s/f
6" x 6" 33%

Trellis

46 pcs. per 100 s/f
12" x 12" 46%
88 pcs. per 100 s/f
6" x 12" 44%
40 pcs. per 100 s/f
6" x 6" 10%

Corridor Layered

40 pcs. per 100 s/f
12" x 12" 40%
80 pcs. per 100 s/f
6" x 12" 40%
80 pcs. per 100 s/f
6" x 6" 20%

Vectored

29 pcs. per 100 s/f
12" x 12" 29%
114 pcs. per 100 s/f
6" x 12" 57%
56 pcs. per 100 s/f
6" x 6" 14%
Tile pattern created with one small square tile, one rectangular tile, and one larger square tile arranged in an L shape.

Block

47 pcs. per 100 s/f
12" x 12" 47%
48 pcs. per 100 s/f
8" x 12" 32%
48 pcs. per 100 s/f
8" x 8" 21%

Modular Rectangle

17 pcs. per 100 s/f
18" x 18" 38%
33 pcs. per 100 s/f
12" x 12" 33%
120 pcs. per 100 s/f
6" x 6" 29%
Tile pattern with one large square tile next to smaller square and rectangular tiles that equal the measurement of the larger square.

Plain Weave

57 pcs. per 100 s/f
12" x 12" 57%
100 pcs. per 100 s/f
6" x 12" 28%
60 pcs. per 100 s/f
6" x 6" 15%
Tile pattern with one large square tile surrounded by smaller square and rectangular tiles.

Soldiered

25 pcs. per 100 s/f
12" x 12" 25%
100 pcs. per 100 s/f
6" x 12" 50%
100 pcs. per 100 s/f
6" x 6" 25%
Tile pattern created with one large square tile, one large rectangular tile, and one larger square tile arranged in an L shape.

Broken Joint

23 pcs. per 100 s/f
18" x 18" 50%
22 pcs. per 100 s/f
12" x 18" 33%
17 pcs. per 100 s/f
12" x 12" 17%

Block Trellis

25 pcs. per 100 s/f
12" x 12" 25%
25 pcs. per 100 s/f
12" x 24" 50%
6 pcs. per 100 s/f
24" x 24" 25%

Checkered Diamond

53 pcs. per 100 s/f
6-1/2" x 6-1/2" 15.5%
53 pcs. per 100 s/f
6-1/2" x 20" 47.8%
13 pcs. per 100 s/f
20" x 20" 36.7%
Tile pattern with two square tiles surrounded by smaller rectangular tiles and a smaller square in the corner.

Diamond Corridor

7 pcs. per 100 s/f
12" x 12" 6.7%
20 pcs. per 100 s/f
12" x 24" 40%
13 pcs. per 100 s/f
24" x 24" 53.3%
Tile pattern with three different size square tiles arranged with the largest then two smaller tiles and medium tile stacked next to the larger square.

Tip Toe

31 pcs. per 100 s/f
6" x 6" 7%
31 pcs. per 100 s/f
12" x 12" 31%
15 pcs. per 100 s/f
24" x 24" 62%
DAL_3TilePattern_VerticalBlock

Linear Stack

43 pcs. per 100 s/f
2" x 24" 14.3%
14 pcs. per 100 s/f
12" x 24" 28.6%
14 pcs. per 100 s/f
24" x 24" 57.1%
Tile pattern created with a column of rectangular tile then a column of square tile, column of rectangualr tile then a column of smaller square tiles all in a grid pattern.

Corridor Modular

40 pcs. per 100 s/f
12" x 12" 40%
40 pcs. per 100 s/f
6" x 12" 20%
160 pcs. per s/f
6" x 6" 40%
DAL_MultipleTilePattern_ModularPinwheel

Pinwheel Modified

55 pcs. per 100 s/f
12" x 18" 83%
14 pcs. per 100 s/f
12" x 12" 14%
12 pcs. per 100 s/f
6" x 6" 3%
Tile pattern with three rectangular tiles of varying widths arranged in offset columns.

Staggered Vertical Brickwork

25 pcs. per 100 s/f
12" x 24" 50%
25 pcs. per 100 s/f
8" x 24" 33.3%
25 pcs. per 100 s/f
4" x 24" 16.7%
DAL_3TilePattern_TriadHopscotch

Triad Hopscotch

29 pcs. per 100 s/f
18" x 18" 66%
28 pcs. per 100 s/f
12" x 12" 28%
24 pcs. per 100 s/f
6" x 6" 6%
